ANE Models - AP012 SmartSwitch board (5V version)(Three position) (SKU 136-AP012)

ANE Smart Switch Component AP012

Features:

  •  Easy to install.
  •  Virtual center line for easy trouble free mounting.
  •  Minimal structural interference---the servo and its mounting linkage are compact in size.
  •  More mounting possibilities---traditional, off-center or horizontal rotary installation. The servo can be installed either below the road bed or next to the turnout.
  •  Adjustable servo speed and position through the programming features in the SmartSwitchTM control board to give you ultimate control for pressing the point rails against the stock rails.
  •  Each control board can control up to four turnouts.
  •  Can use the toggle switch and the push button to trigger servo movement.
  •  Can simultaneously control one or up to four servos by using one toggle switch or push button.
  •  Remember the turnout positions when power is off.
  •  Provides various settings for indication and signal light.
  •  DCC friendly--- the SmartSwitchTM stationary decoder supports a full range  of DCC accessory addresses (1-2048) and offers simple mainline address programming.
  •  The decoder also supports route control features from major DCC manufacturers.
  •  Provide extra 2 set three position function, suppoert to control three position turnout and semaphores

For more technical information click Here







$19.95 US
Country of Origin: Taiwan
