ANE Smart Switch Set A005

Consists of:

â–º 4 AP007 Jumbo Servo Motors (for larger scale turnouts)
â–º Cables and mounting hardware
â–º Does Not Contain AP001 Smart Switch Board

Product Features

•  Easy to install.
•  Built-in drilling template.
•  Virtual center line for easy trouble free mounting.
•  Minimal structural interference---the servo and its mounting linkage are compact in size.
•  More mounting possibilities---traditional, off-center or horizontal rotary installation. The servo can be installed either below the road bed or next to the turnout.
•  Adjustable servo speed and position through the programming features in the SmartSwitchTM control board to give you ultimate control for pressing the point rails against the stock rails.
•  Each control board can control up to four turnouts.
•  Can use the toggle switch and the push button to trigger servo movement.
•  Can simultaneously control one or up to four servos by using one toggle switch or push button.
•  Remember the turnout positions when power is off.
•  Provides various settings for indication and signal light.
•  Low current draw. 9V is the minimum requirement for the input power supply.
•  DCC friendly--- the SmartSwitchTM stationary decoder supports a full range of DCC accessory addresses (1-2048) and offers simple mainline address programming.
•  The decoder also supports route control features from major DCC manufacturers.
•  The SmartFrogTM has easy DCC friendly power route wiring. The precise polarity switch when both the point rails are not in contact with the stock rails allows for zero chance of short    circuit.

The SmartSwitchTM gives you the ultimate flexibility.
