SKU: 1489 The K5D7 is a drop-in decoder for the upcoming Kato N Scale F40PH. This decoder includes an extra It has 7 functions with built-in onboard resistor for LED's, 3 onboard, superbright LED's which provide the forward light and red marker light as well as the reverse light (which does not light from the factor). Note: Four of the functions (F1-F4) have onboard resistors for LED's and 1.5v bulbs. The remaining function (F5) output at 12v and will need external resistors if you plan to use LED's or 1.5v bulbs. Included is our auto-adjusting BEMF for outstanding slow speed performance and hassle free set up. Also includes Quiet Drive for super quiet engine performance.

Dimensions: 2.344”x0.49”x0.097” or 59.53mm x 12.46mm x 2.46mm

Main Features of this Decoder

• Back EMF Load Compensation for superior slow speed control even with heavy loads.
• Quiet Drive creates SUPER QUIET engine performance.
• Autodetect for realistic throttle response when using DC power.
• Function Remapping
• 3 Point Acceleration/Deceleration Curves
• Button Control of the Motor
• Loadable Speed Tables
• Various lighting effects
• Decoder lock
